Square D 9001K52J1FG

Name: Square D 9001K52J1FG
Brand: Square D
SKU: CS1476615
Availability: OutOfStock

SKU: CS1476615MPN: 9001K52J1FGUPC/EAN: 785901959519

Illuminated selector switch head, Harmony 9001K, metal, long handle, green, 30mm, 3 positions, spring return both sides to center, 110-120V

Product Details

Harmony Selector switch Dia 30, 3 positions, spring return, incandescent

Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-70 °C
Bezel Material	chromium plated metal
Bulb Base	BA 9s
Contacts Type And Composition	without contact block
Device Presentation	basic element
Device Short Name	9001K
Mechanical Durability	500000 cycles
Mounting Diameter	30 mm
Operator Position Information	3 positions
Product Certifications	UL 508# #NEMA
Product Or Component Type	illuminated selector switch
Protective Treatment	TC
Range Of Product	Harmony 9001K
Shape Of Signaling Unit Head	round
Standards	EN/IEC 60947-1# #EN/IEC 60947-5-4# #UL 508# #JIS C 852# #CSA C22.2 No 14# #JIS C 4520# #EN/IEC 60947-5-1
