All ProductsEaton

Eaton 14100AQD03

SKU: CS935283MPN: 14100AQD03Alternate Part #s: 14100AQD03EAT-14100AQD03UPC/EAN: 782113843667

Eaton Comet 18mm tubular photoelectric sensor

Eaton 14100AQD07
$490.54
Unit
Available on backorder
remove
add

Product Details

Eaton Comet Series Tubular Photoelectric Sensor, Forward Viewing, Sensor dist 25 Ft., 300 mA max AC L1 switched/DC NPN open coll, 300 mA AC/DC at 20-264Vac/15-30Vdc, 4 Pin Dual Key Micro Connector, Non Polarized Retroreflective, 8 in(.2m)

Attributes

Cable Type Polyvinyl Chloride (PVC)
Connection 4-pin dual key micro connector
Contact Configuration AC: L1 switched DC: NPN open collector
Contact Rating 300 mA AC/DC at 20-264Vac/15-30Vdc
Enclosure Material Lens: polycarbonate Cable jacket: PVC Body: structural polyurethane foam
Environmental Rating NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K
Input Voltage 20-264 Vac, 15-30 Vdc
Led Indicator Output status: red
Maximum Ac Current 300 mA
Maximum Dc Current 300 mA
Operating Mode Non polarized retroreflective
Operating Temperature Max 158 FAH
Operating Temperature Max Uom FAH
Operating Temperature Min -40 FAH
Operating Temperature Min Uom FAH
Protection Latching short circuit
Sensor Type Retroreflective
Switch Type Photoelectric

Specifications

SKUCS935283
MPN14100AQD03
Alternate Part #s14100AQD03, EAT-14100AQD03
UPC/EAN782113843667
