Resideo SV9520H8513

Fast-Slow Opening Direct Hot Surface Ignition SmartValve

½ in. NPT x ½ in. NPT Direct Hot Surface Ignition SmartValve Control with fast-slow opening and 3.5 in. wc pressure regulator setting

Note: This model includes an LP Conversion Kit

Product Line Overview

The SV9520 SmartValve System Controls combine gas flow control and electronic direct main burner ignition sequencing functions into a single unit.

Features

• The control communicates directly with the ST9160 Electronic Fan Timer (EFT) in typical forced warm air furnace applications.

• It will also interface with the 208907 Terminal Board, providing compatibility with power-stealing thermostats. Or, it directly interfaces with the appropriate power supplies and a system thermostat for additional appliance applications.

• When controlled directly by a thermostat, the control does not provide a postpurge function, as power to the control is removed when the thermostat call for heat ends.

• This system is suitable for a wide range of fan-assisted combustion, gas-fired appliances including furnaces, rooftop furnaces, boilers, unit heaters, infrared heaters, water heaters and commercial cooking appliances.

Specifications

• Flame Sense: Two Rod

• Type of Gas: Natural

• Ignition System Type: Direct Hot Surface Pilot Ignition

• Ignition Sequence: 7/12 sec

• Ignition Trials To Lockout: 4 trials

• PrePurge: 15 seconds

• Body Pattern: Straight-through

• Opening Characteristics (standard, step): Fast Slow Opening

• Control Voltage (Thermostat or other call for heat): 24 Vac, 60 Hz

• Ignition Trial Time (sec): 90 Sec

• Electrical Ratings: 24 Vac

• Frequency: 60 Hz

• Frequency: 50 Hz

• Flame Failure Response Time (sec): 2 sec @ 5 µA

• Ambient Temperature Range (F): 0 F to +175 F

• Ambient Temperature Range (C): -18 C to +79 C

• Dimensions (in.): 3.2 in. wide x 4.9 in. high x 4.1 in. long

• Dimensions (mm): 81 mm wide x 124 mm high x 104 mm long

• Pressure Regulator Setting (psi): 3.5 in. wc

• Pressure Regulator Setting (kPa): 0.87 kPa

• Pressure Ratings (psi): ½ psi

• Pressure Ratings (kPa): 3.5 kPa

• Inlet/Outlet Size (in.): ½ in. NPT x ½ in. NPT

• Maximum Capacity (ft³/hr): 200 ft³/hr

• Maximum Capacity (m³/hr): 5.7 m³/hr

• Minimum Capacity (ft³/hr): 20 ft³/hr

• Minimum Capacity (m³/hr): 0.6 m³/hr

• Maximum Capacity at 1 in. P.D. (ft³/hr): 150 ft³/hr

• Maximum Capacity at 1 in. P.D. (m³/hr): 4.2 m³/hr

• Pressure Tapping: ⅛ in. - NPT

• Mounting: 0 to 90 degrees in any direction from the upright position of the gas control knob, including vertically.

• Approvals, Canadian Standards Association: CSA International: 158158-10592145

• Tradeline Value: Super Tradeline
