Siemens 599-02042
SKU: CS593865MPN: 599-02042UPC/EAN: 804766016615
MT Series ½” 2W Valve, 4.0Cv, NO, Mod Eq Percent, Brass Trim, FxUM, ANSI 250

$76.36
Unit1 in stock
Product Details
Powermite MT Series, ½” 2-Way, 4.0 Cv, NO, Modified Equal Percentage, F×UM, Brass Body, Brass Trim, ANSI Class 250, Designed to work with pneumatic or electronic actuators, Direct-coupled universal bonnet, 10 to 15 psi spring range, No tools required f
Attributes
| End Connection | FxUM |
| Flow Characteristic | Modified Equal-percentage |
| Flow Coefficient Cv | 4.0000 |
| Medium Temperature | 35…250 ºF |
| Medium Temperature F Max | 250 ºF |
| Medium Temperature F Min | 35 ºF |
| Mounting Position | any |
| Normally Open Normally Closed | Normally Open |
| Permissible Operating Pressure | 2758 kPa; 400 psi |
| Trim Material | Brass |
| Valve Body Style | Stroke-Globe |
| Valve Size | 0.5 in |
| Valve Type | Two-way |
Specifications
| SKU | CS593865 |
|---|---|
| MPN | 599-02042 |
| UPC/EAN | 804766016615 |
