Omega HH509
SKU: CS5803269MPN: HH509
1 \& 2 Channel K \& J Thermocouple NEMA-4X Temperature Meter
$267.58
UnitAvailable on backorder
Product Details
- NEMA-4X Dustproof
- Water/Splash Resistant
- Warning Beeper with Hi/Lo Setting, Time Setting
- Clock and Elapsed Time
Attributes
| Width | 91 mm |
| Height | 192 mm |
| Weight | 255 g |
| Diameter | 53 mm |
| Series ID | HH508-509 |
| Weight Note | Approx 255 g (9 oz) |
| Battery life | 200 hr |
| Display Note | Number of Digits : 1999 |
| Display Type | Backlit LCD |
| Sampling Rate | 2.5 Hz (2.5 updates/second) |
| Supply Voltage | 9 Vdc |
| Country of Origin | Taiwan |
| Thermocouple Type | J, K, T, E, S |
| Number of Channels | 2 |
| Sampling Rate Note | 2.5 times per second |
| Temperature Accuracy | ± 0.1% |
| Additional Features 1 | Data Hold, Max/Min, Relative, Hi/Lo Limits with Beeper Warning, Auto Power Off, T1-T2 (HH509 only) |
| Electrical Connection | Sub-D Male Miniature Connector |
| Temperature Resolution | 0.1 °C |
| Temperature Sensor Type | Thermocouple |
| Temperature Accuracy Note | 0.1% +1°C |
| Temperature Resolution Note | 0.1°/1° |
| Relative Humidity Accuracy Note | @ 23 ± 5°C<75% RH |
| Measuring Temperature Range, Max | 1767 °C |
| Measuring Temperature Range, Min | -210 °C |
Specifications
| SKU | CS5803269 |
|---|---|
| MPN | HH509 |
