Veris H221
SKU: CS565337MPN: H221Alternate Part #: VER-H221UPC/EAN: 694776919507
Current Sensor: 4-20mA Loop Powered Output, Split-Core, 100-300 Amps, UL Listed for use on 75 deg. C insulated conductors, CE, RoHS Compliant
$157.33
Unit2 in stock
Product Details
Current Sensor:
- 4-20mA Loop Powered Output* Split-Core Housing* 100-300 Amps* UL Listed for use on 75 deg. C insulated conductors* CE* RoHS Compliant
Attributes
| Analogue Output Type | 4…20 mA |
| Product or Component Type | sensor |
| Ambient Air Temperature for Operation | -15-60 °C |
| Product Certifications | UL; CE |
| Type of Measurement | AC current |
| Device Application | building automation systems |
| Mounting Support | split core housing |
| Sensor Type | current transducer, AC |
| Relative Humidity | 10-90 % RH, non-condensing |
| Network Frequency | 50…60 Hz |
| AWG Gauge | AWG 22…AWG 12 |
| Current Measurement Range | 0…300 A |
| Current Measurement Accuracy | ± 2 % of full scale above 30 A |
| Opening Width | 35 mm |
Specifications
| SKU | CS565337 |
|---|---|
| MPN | H221 |
| Alternate Part # | VER-H221 |
| UPC/EAN | 694776919507 |
