Turck TBEN-LL-4RMC-4DIP-4DXP
SKU: CS5391096MPN: TBEN-LL-4RMC-4DIP-4DXPAlternate Part #: 100018352UPC/EAN: 4047101524055
Contact us for pricing and availability
Product Details
Compact multiprotocol I/O module for Ethernet
4 Roller Motor Controllers
4 digital PNP inputs, 4 universal digital channels, configurable as PNP inputs or 2A outputs
- PROFINET device, EtherNet/IP device or Modbus TCP slave
- Integrated Ethernet switch
- Supports 10 Mbps / 100 Mbps
- 2x M12, 4-pin, D-coded, Ethernet fieldbus connection
- Glass fiber reinforced housing
- Shock and vibration tested
- Fully potted module electronics
- Protection classes IP65, IP67, IP69K
- Roller motor controller for Interroll RollerDrive
- Programmable ARGEE
Attributes
| Ambient Temperature | -40…+70 °C |
| Approvals | cULus |
| Connection Technology Signal | M12 |
| Customs Tariff Number | 85176200000.0000 |
| Device Type | I/O Module, Compact station, Field Logic Controller (ARGEE) |
| Ecl Ss Code V5 1 4 | 27250302 -/- Digital I/O module (periphery) |
| Fieldbus Connection Technology | 2 x M12, 4-pin, D-coded |
| Fieldbus Protocol | Modbus TCP, EtherNet/IP, PROFINET |
| Fieldbus Transmission Rate | 10/100 Mbps |
| Protection Class | IP65/IP67/IP69K |
| Signal Type | Roller motor, Digital input, Digital input/output, Digital input |
Specifications
| SKU | CS5391096 |
|---|---|
| MPN | TBEN-LL-4RMC-4DIP-4DXP |
| Alternate Part # | 100018352 |
| UPC/EAN | 4047101524055 |
