Eaton 1551E-6533
SKU: CS5019695MPN: 1551E-6533UPC/EAN: 782116112296
Eaton Enhanced 50 photoelectric sensor
$454.76
UnitAvailable on backorder
Product Details
Eaton Enhanced 50 Series Photoelectric Sensor, Sensor dist. depends on the fiberoptic cables, Iso SS Relay, 300 mA at 240 Vac/Vdc, 4 Pin Dual Key Micro Pigtail Connector, 12–240 Vdc 24–240 Vac input, short circuit/overload
Attributes
| Cable Type | Polyvinyl Chloride (PVC) |
| Connection | 4-pin dual key micro pigtail connector |
| Contact Configuration | Isolated solid state relay |
| Contact Rating | 300 mA at 240 Vac/Vdc |
| Enclosure Material | Fiberglass reinforced plastic |
| Environmental Rating | IP67, IP69K |
| Input Voltage | 12-240 Vdc, 24-240 Vac |
| Led Indicator | Power on: yellow Output status: green Marginal gain: red |
| Maximum Ac Current | 300 mA |
| Maximum Dc Current | 300 mA |
| Operating Mode | Fiber-optic Visible red |
| Operating Temperature Max | 131 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -13 FAH |
| Operating Temperature Min Uom | FAH |
| Protection | Reverse polarity and short circuit protected |
| Sensor Type | Fiberoptic |
| Switch Type | Photoelectric |
Specifications
| SKU | CS5019695 |
|---|---|
| MPN | 1551E-6533 |
| UPC/EAN | 782116112296 |
