Eaton 13102A6513
SKU: CS5018819MPN: 13102A6513UPC/EAN: 782113928180
Eaton Comet 18mm tubular photoelectric sensor
Contact us for pricing and availability
Product Details
Eaton Comet 18mm tubular photoelectric sensor, Forward Viewing, Sensor dist 1.6 in, 300 mA max AC L1 switched/DC NPN open coll, 300 mA AC/DC at 20-264Vac/15-30Vdc Cable, 20-264 Vac/15-30 Vdc input, Focused Spot Diffuse
Attributes
| Cable Type | Polyvinyl Chloride (PVC) |
| Connection | 6.6 ft (2 m) cable |
| Contact Configuration | DC: NPN open collector AC: L1 switched |
| Contact Rating | 300 mA AC/DC at 20-264Vac/15-30Vdc |
| Enclosure Material | Body: structural polyurethane foam Lens: polycarbonate Cable jacket: PVC |
| Environmental Rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K |
| Input Voltage | 20-264 Vac, 15-30 Vdc |
| Led Indicator | Output status: red |
| Maximum Ac Current | 300 mA |
| Maximum Dc Current | 300 mA |
| Operating Mode | Focused spot diffuse |
| Operating Temperature Max | 158 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -40 FAH |
| Operating Temperature Min Uom | FAH |
| Protection | Latching short circuit |
| Sensor Type | Focused diffuse |
| Switch Type | Photoelectric |
Specifications
| SKU | CS5018819 |
|---|---|
| MPN | 13102A6513 |
| UPC/EAN | 782113928180 |
