Turck RSF RKF 57/22
SKU: CS496198MPN: RSF RKF 57/22Alternate Part #: U2309-6
U2309-6 - RECEPT,⅞IN.MINIFAST
$56.11
UnitAvailable on backorder
Product Details
DeviceNet™ Receptacle
Panel Feed-through
- Male ⅞″ minifast Receptacle
- Female ⅞″ minifast Receptacle
- Design: ⅞” adapter
- 5-pin feedthrough male/female
- For use in CAN (DeviceNet, CANopen) applications
- Ampacity: 9 A
- Rated voltage: 600 V
- Temperature range: -40 °C…+105 °C
- Protection class: NEMA 1, 3, 4 and IEC IP67
Attributes
| Accessory Type | Adapter |
| Application | Data |
| Connector A | Male, ⅞″-16 UN, Straight |
| Connector B | Female, ⅞″-16 UN |
| Connector Body | Metal, CuZn, nickel-plated |
| Current | 9 A |
| Customs Tariff Number | 85366990990.0000 |
| Design | Double-ended |
| Device Type | Wall feedthrough |
| Ecl Ss Code V5 1 4 | 27250391 -/- Decentralized periphery (parts) [AKP191002] |
| Fieldbus Protocol | DeviceNet |
| Housing Material Finish | Brass, CuZn, Nickel-plated |
| Mounting Orientation | Front mount |
| Mounting Thread | ⅞″-16 UN |
| Mounting Thread B | ⅞″-16 UN |
| Mounting Type | Rear mount |
| Number Of Contacts | 5 |
| Voltage | 600 V |
Specifications
| SKU | CS496198 |
|---|---|
| MPN | RSF RKF 57/22 |
| Alternate Part # | U2309-6 |
