Eaton LSM-20A-LA

Name: Eaton LSM-20A-LA
Brand: Eaton
SKU: CS4896320
Price: 162.19 USD
Availability: OutOfStock

SKU: CS4896320MPN: LSM-20A-LAUPC/EAN: 786685392226

Eaton LS-Titan miniature DIN limit switch

Eaton LS-11S-S, LS-11S-ZB, LS-S02-LA, LS-S02-LB, LS-S02-LS, LS-S02-OR, LS-S02-P, LS-S02-RL, LS-S02-RLA, LS-S02-RLA30, LS-S02-RLA40, LS-S02-RLA40R, LS-S02-RR, LS-S02-RRM, LS-S02-S

Product Details

Eaton LS-Titan Miniature DIN Limit Switch, Angled Roller Lever, Die Cast Zinc enclosure, 6A max AC, 3A max DC, 2 NO, Slow Make Break, 6A at 240Vac, 3A at 24Vdc, Cage Clamps

Attributes

Connection	Cage clamps
Contact Configuration	2 NO, slow make break
Contact Rating	6A at 240Vac, 3A at 24Vdc
Enclosure Material	Die cast zinc
Environmental Rating	IP66, IP67
Maximum Ac Current	6 A
Maximum Dc Current	3 A
Operating Temperature Max	158 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	-13 FAH
Operating Temperature Min Uom	FAH
Switch Type	Angled roller lever
Type	LS-Titan

Specifications

SKU	CS4896320
MPN	LSM-20A-LA
UPC/EAN	786685392226
