Eaton E57EAL12T110ED
SKU: CS4872817MPN: E57EAL12T110EDUPC/EAN: 782113931548
Eaton E57 inductive proximity sensor
Contact us for pricing and availability
Product Details
Eaton E57 Small dia Series Inductive Proximity Sensor, 0.47 dia, Straight, Sensor dist: 4mm dist, 200mA max DC, NPN Open Collector, NO, 200mA at 30Vdc, 4 Pin M12 Connector, 10-30Vdc input, \< 1% accuracy, Short circuit protected, Un-shielded
Attributes
| Accuracy | < 1% |
| Actuator Function | Unshielded |
| Connection | 4-pin M12 connector |
| Contact Configuration | NPN open collector, NO |
| Contact Rating | 200 mA at 30 Vdc |
| Enclosure Material | Stainless steel |
| Environmental Rating | NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP67 |
| Input Voltage | 10-30 Vdc |
| Led Indicator | Output status: red |
| Maximum Dc Current | 200 mA |
| Operating Temperature Max | 158 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -13 FAH |
| Operating Temperature Min Uom | FAH |
| Protection | Short circuit protected |
| Sensor Type | Inductive proximity |
| Series | E57 |
Specifications
| SKU | CS4872817 |
|---|---|
| MPN | E57EAL12T110ED |
| UPC/EAN | 782113931548 |
