Eaton E50ALM16P
SKU: CS4871683MPN: E50ALM16PUPC/EAN: 782113726793
Eaton E50 NEMA heavy duty plug-in limit switch
Contact us for pricing and availability
Product Details
Eaton E50 Heavy Duty Factory Sealed 6P+ Limit Switch,8 Ft.( 2.5m )Cable,10Aat240Vac,1Aat125Vdc,SOOW-A,1NO-1NC,96Foot,Die Cast Zinc,NEMA 1,3,3S,4,4X,6,6P,13,IP67,IP69K,LED(24–120 Vac/dc),10A,1A,14°to201°F,Side Rotary,Maintnd
Attributes
| Accuracy | Refer to installation publication P15836 |
| Cable Type | SOOW-A |
| Connection | 8 ft (2.4 m) cable |
| Contact Configuration | 1 NO-1 NC |
| Contact Rating | 10A at 240Vac, 1A at 125Vdc |
| Enclosure Material | Die cast zinc |
| Environmental Rating | NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67, IP69K |
| Led Indicator | LED (24-120 Vac/dc) |
| Maximum Ac Current | 10 A |
| Maximum Dc Current | 1 A |
| Operating Temperature Max | 201 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | 14 FAH |
| Operating Temperature Min Uom | FAH |
| Switch Type | Maintained Side rotary |
Specifications
| SKU | CS4871683 |
|---|---|
| MPN | E50ALM16P |
| UPC/EAN | 782113726793 |
