Square D XVC1B1SK

Name: Square D XVC1B1SK
Brand: Square D
SKU: CS4814169
Availability: OutOfStock

SKU: CS4814169MPN: XVC1B1SK

Harmony XVC, Monolithic precabled tower light, plastic, red, Ø100, base mounting, steady or flashing, buzzer, IP54, 24 V DC

Product Details

100mm Tower R Base Mount Buzzer Flash

Uimp Rated Impulse Withstand Voltage	0.8 kV
Us Rated Supply Voltage	24 V
Us Rated Supply Voltage 1	24 V
Ambient Air Temperature For Operation	-30-50 °C
Ambient Air Temperature For Operation 1	-30-50 °C
Ambient Air Temperature For Storage	-35-70 °C
Awg Gauge	AWG 22# #AWG 18
Beacon Or Indicator Bank Unit Type	1 illuminated unit
Cable Cross Section	0.83-0.83 mm²# #0.33-0.33 mm²
Component Name	XVC
Current Consumption	150 mA
Flashing Frequency	0.7-3 Hz
Flashing Frequency 1	0.7-3 Hz
Marking	CE
Marking 1	CE
Mounting Diameter	100 mm
Product Certifications	UL
Product Mounting	on base
Product Or Component Type	complete pre-wired monolithic tower light
Protective Treatment	TC
Range Of Product	Harmony XVC1
Sound Signalling	buzzer
Standards	EN/IEC 61000-6-2# #EN/IEC 61000-6-3# #EN/IEC 61000-6-4
Supply Circuit Type	DC
