APC SRT3000RMXLT-5KTF

Name: APC SRT3000RMXLT-5KTF
Brand: APC
SKU: CS4805380
Availability: OutOfStock

SKU: CS4805380MPN: SRT3000RMXLT-5KTFUPC/EAN: 731304634720

APC Smart-UPS On-Line, 3kVA, Rackmount 4U, 208V, 12x 5-20R+2x L6-20R NEMA outlets, SmartSlot, W/ transformer 208V to 120V, W/ rail kit

Product Details

APC Smart UPS SRT 3000VA RM 208V to 120V 2U Step-Down Transformer

Attributes

Sena Acoustic Level	55 dBA
Sena Additional Information	Configurable for 208 or 240 nominal output voltage
Sena Additional Specification	high density
Sena Alarm	audible and visible alarms prioritized by severity
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	165 W rated
Sena Battery Curve	D
Sena Battery Life	3-5 year(s)
Sena Battery Option	SRT96RMBP 1 1491 VAh SRT96RMBP 10 10437 VAh SRT96RMBP 2 2485 VAh SRT96RMBP 3 3479 VAh SRT96RMBP 4 4473 VAh SRT96RMBP 5 5467 VAh SRT96RMBP 6 6461 VAh SRT96RMBP 8 8449 VAh
Sena Battery Recharge Time	3 h
Sena Battery Type	lead-acid battery
Sena Battery Voltage	96 V
Sena Bypass Type	internal bypass (automatic and manual)
Sena Control Panel	multifunction LCD status and control console
Sena Crest Factor	0.126
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.021199999377131
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.029999999329448
Sena Curve Proportional Loss	0.021999999880791
Sena Curve Square Loss	0.02419999986887
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the ENERGY STAR Test Method for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 240V/60Hz electrical input and balanced resistive load (PF =
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Emergency Power Off	yes
Sena Extended Runtime	1.0000
Sena Free Slots	1.0000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 2 %
Sena Heat Dissipation	773 Btu/h
Sena Input Voltage	208 V
Sena Input Voltage 1	208 V
Sena Input Voltage Limits	100…275 V adjustable (half load)
Sena Ip Degree Of Protection	IP20
Sena Maximum Configurable Power In Va	3000 VA
Sena Maximum Configurable Power In W	2700 W
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Position	horizontal
Sena Mounting Preference	lower
Sena Nb Of Power Socket Outlets	12 NEMA 5-20R 2 NEMA L6-20R
Sena Network Frequency	40…70 Hz auto-sensing
Sena Number Of Battery Filled Slots	1.0000
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Cables	1.0000
Sena Number Of Rack Unit	4U
Sena Number Of Tare Power	53 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V 208 V
Sena Output Voltage 1	120 V 208 V
Sena Performance Multiplier	1.0000
Sena Plug Standard	NEMA L6-20P
Sena Product Certifications	ENERGY STAR V2.0 (USA)
Sena Provided Equipment	CD with software documentation CD installation guide rack mounting brackets rack mounting hardware rack mounting support rails USB cable warranty card
Sena Provided Equipment 1	CD with software documentation CD installation guide rack mounting brackets rack mounting hardware rack mounting support rails USB cable warranty card
Sena Provided Equipment 2	CD with software documentation CD installation guide rack mounting brackets rack mounting hardware rack mounting support rails USB cable warranty card
Sena Rated Power In Va	3000 VA
Sena Rated Power In W	2700 W
Sena Redundant	No
Sena Relative Humidity	0-95 % non-condensing
Sena Show Note Op Temperature	No
Sena Size Ups Version	internetworking# #server# #telecom
Sena Standards	CSA C22.2 No 107.3-05# #FCC part 15 class A# #UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 % non-condensing
Sena Surge Energy Rate	340 J
Sena Ups Design Life	7 year(s)
Sena Ups Size	S
Sena Ups Type	double conversion online
Sena Usb Compatible	Yes
Sena Value Multiplier	1.0000
Sena Wave Type	sine wave
