APC SMX2000LVNC

Name: APC SMX2000LVNC
Brand: APC
SKU: CS4805360
Availability: OutOfStock

SKU: CS4805360MPN: SMX2000LVNCUPC/EAN: 731304292593

APC Smart-UPS X, Line Interactive, 2000VA, Rack/tower convertible 4U, 100V-127V, 6x 5-15R+3x 5-20R+1x L5-20R NEMA, NMC, Extended runtime, Short depth

Product Details

Smart-UPS X 2000VA Rack/Tower LCD 100-127V with Network Card

Attributes

Sena Acoustic Level	55 dBA
Sena Additional Specification	network card pre-installed
Sena Alarm	alarm when on battery : distinctive low battery alarm : configurable delays
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	229 W rated
Sena Battery Curve	C
Sena Battery Life	3-5 year(s)
Sena Battery Option	SMX120BP 1 2070 VAh SMX120BP 10 14490 VAh SMX120BP 2 3450 VAh SMX120BP 3 4830 VAh SMX120BP 4 6210 VAh SMX120BP 6 8970 VAh SMX120BP 8 11730 VAh
Sena Battery Recharge Time	3 h
Sena Battery Type	lead-acid battery
Sena Control Panel	LED status display with on line : on battery : replace battery and overload indicators# #multifunction LCD status and control console
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.010300000198185
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.019999999552965
Sena Curve Square Loss	0.012699999846518
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the ENERGY STAR Test Method for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 120V/60Hz electrical input and balanced resistive load (PF =
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Equipment Protection Policy	lifetime : $150000
Sena Extended Runtime	1.0000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 5 %
Sena Heat Dissipation	203 Btu/h
Sena Input Voltage	120 V
Sena Input Voltage 1	120 V
Sena Input Voltage Limits	70…153 V 75…154 V adjustable
Sena Maximum Configurable Power In Va	1920 VA
Sena Maximum Configurable Power In W	1800 W
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Preference	lower
Sena Nb Of Power Socket Outlets	1 NEMA L5-20R 3 NEMA 5-20R 6 NEMA 5-15R
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Noise Suppression	full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Sena Number Of Battery Filled Slots	1.0000
Sena Number Of Cables	1.0000
Sena Number Of Rack Unit	4U
Sena Number Of Tare Power	40 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Performance Multiplier	1.0000
Sena Plug Standard	NEMA 5-20P
Sena Preinstalled Device	network management card 2 with environmental monitoring
Sena Product Certifications	BSMI# #CSA# #NOM# #TÜV# #VCCI class A
Sena Provided Equipment	CD with software documentation CD installation guide network management card rack mounting brackets rack mounting hardware rack mounting support rails Smart UPS signalling RS-232 cable USB cable
Sena Provided Equipment 1	CD with software documentation CD installation guide network management card rack mounting brackets rack mounting hardware rack mounting support rails Smart UPS signalling RS-232 cable USB cable
Sena Provided Equipment 2	CD with software documentation CD installation guide network management card rack mounting brackets rack mounting hardware rack mounting support rails Smart UPS signalling RS-232 cable USB cable
Sena Rated Power In Va	1920 VA
Sena Rated Power In W	1800 W
Sena Redundant	No
Sena Relative Humidity	0-95 %
Sena Show Note Op Temperature	No
Sena Size Ups Version	internetworking# #server# #telecom
Sena Standards	EN 50091-2# #EN 55022 class A# #FCC part 15 class A# #UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Surge Energy Rate	540 J
Sena Transfer Time	4 ms typical : 8 ms maximum
Sena Two Post Mountable	1.0000
Sena Ups Design Life	6 year(s)
Sena Ups Size	S
Sena Ups Type	line interactive
Sena Usb Compatible	No
Sena Value Multiplier	1.0000
Sena Wave Type	sine wave
