Dwyer MTL5541

Name: Dwyer MTL5541
Brand: Dwyer
SKU: CS4119597
Price: 1481.18 USD
Availability: OutOfStock

SKU: CS4119597MPN: MTL5541Alternate Part #: 124372-52

MTL5541 REPEATER POWER SUPPLY

$1,481.18

Unit

Available on backorder

Quantity

remove

add

Product Details

Galvanic barrier

Commodity Code	R6GA
Compliance	See table on catalog page.
Current Consumption 20 Ma Signal	51 mA @ 24V.
Hazardous Area Input	Signal range: 0 to 24 mA (including over-range); Transmitter voltage: 16.5 V at 20 mA.
Humidity	5 to 95% RH.
Isolation	250 V RMS, tested at 1500 V RMS minimum, between safe- and hazardous-area terminals; 50 V between safe-area circuits and power supply.
Led Indicator	Green: Power Indication.
Maximum Power Dissipation 20 Ma Signal	0.7 W @ 24 VDC, 1.0 W @ 24 VDC.
Mounting	T-section 35mm DIN rail (7.5 or 15mm) to EN 50022.
Power Requirement	20 to 35 VDC.
Response Time	Settles to within 10% of final value within 50 µs.
Safe Area Output	Signal range: 4 to 20 mA; Under/over-range: 0 to 24 mA;Load resistance: 0 to 360Î© @ 24 mA, or 0 to 450Î© @ 20 mA; Current sink: 600Î© max.; Maximum Voltage Source: 24 VDC; Output resistance: > 1 MÎ©.
Safety Description	Vo= 28 V, Io= 93 mA, Po= 651mW, Um= 253 RMS or DC.
Temperature Drift	< 0.8µA/°C.
Terminals	Accommodate up to 2.5 mm2 stranded or single-core.
Transfer Accuracy At 68 F 20 C	Better than 15 µA.
