Dwyer DFS2-DM20

Name: Dwyer DFS2-DM20
Brand: Dwyer
SKU: CS4117187
Price: 432.13 USD
Availability: InStock

SKU: CS4117187MPN: DFS2-DM20Alternate Part #: 128099-03

DFS2-DM20 20’ CAP CONT W/MANUA

$432.13

Unit

1 Unit Available at Factory - Ships Same/Next Business Day

Quantity

remove

add

Product Details

Low limit temperature control, 20 ft capillary with manual reset

Cable Entry	(1) M20 compression fitting.
Capillary Material	Copper.
Capillary Overload Temperature	392°F (200°C), maximum 60 minutes.
Commodity Code	R3HB
Compliance	CE.
Deadband	1.8°F (fixed).
Electrical Connection	Two each NO/NC/Common.
Electrical Connections	Two each NO/NC/Common.
Electrical Rating	24 to 250 VAC, 15 (8) A.
Enclosure	Galvanized steel base, ABS cover.
Enclosure Rating	NEMA 1 (IP40).
Humidity Limit	0 to 95% RH, non-condensing.
Low Level Setpoint	Factory Set: 39°F (4°C), and safety lock secured; Adjustment via screwdriver slot.
Operating Temperature	14°F to 54°F (-10°C to 12°C).
Reset Action	Available in automatic or manual reset options.
Sensing Element	Vapor-filled capillary.
Storage Temperature	14°F to 158°F (-10°C to 70°C).
Wire Connection	Terminal with wire-retaining screws.
Wire Size	Max. 14 AWG.
