Turck TTMS-206A-G1/2-LI6-H1140-L300/I250- 0 /500
SKU: CS3878085MPN: TTMS-206A-G1/2-LI6-H1140-L300/I250- 0 /500Alternate Part #s: 100004226TUR-TTMS-206A-G1/2-LI6-H1140-L300/I250-0/500UPC/EAN: 4047101496369
100004226 - PT100, TRANSMITTER, GEN., GE
Contact us for pricing and availability
Product Details
Temperature Detection
With Current Output
- Miniature design
- Analog output 4…20 mA
- Factory setting 0…500 °C
- Process connection G½”, male thread
- Bendable probe (min. bending radius: 3x outer diameter; excluding 30-mm probe tip)
- Probe tapered from 6 mm to 4.4 mm
Attributes
| Ambient Temperature | -40…+80 °C |
| Approvals | CE |
| Current Output | 4…20 mA |
| Customs Tariff Number | 90251900900.0000 |
| Design | Without display (integrated probe) |
| Detection Type | medium contact |
| Ecl Ss Code V5 1 4 | 27200206 -/- Transducer (temperature) |
| Electrical Connection | Connector, M12 × 1 |
| Electrical Output | Current output (2-wire) |
| Housing Material | Stainless steel, 1.4404 (AISI 316L) |
| Measuring Range | 0…500 °C |
| Operating Voltage | 5…32 VDC |
| Process Connection | G ½″ male thread |
| Protection Class | IP67 |
Specifications
| SKU | CS3878085 |
|---|---|
| MPN | TTMS-206A-G1/2-LI6-H1140-L300/I250- 0 /500 |
| Alternate Part #s | 100004226, TUR-TTMS-206A-G1/2-LI6-H1140-L300/I250-0/500 |
| UPC/EAN | 4047101496369 |
