Turck RU40U-M18MS-AP8X2-H1151
SKU: CS3875301MPN: RU40U-M18MS-AP8X2-H1151Alternate Part #: 1610105UPC/EAN: 4047101430240
1610105 - DIF., BARREL, DIG.COM., CON. M
$381.36
UnitAvailable on backorder
Product Details
Ultrasonic Sensor
Diffuse Mode Sensor
- Rectangular transducer front
- Cylindrical housing M18, potted
- Connection via M12 x 1 male
- Temperature compensation
- Blind zone: 2.5 cm
- Range: 40 cm
- Resolution: 0.5 mm
- Aperture angle of sonic cone: ±15 °
- PNP switching output
- NO/NC programmable
- IO-Link
Attributes
| Ambient Temperature | -25…+70 °C |
| Approvals | CE, cULus |
| Communication Protocol | IO-Link |
| Construction Size | M18 x 1 |
| Customs Tariff Number | 85365019900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27272803 -/- Ultrasonic proximity switch |
| Electrical Connection | Connector, M12 × 1 |
| Function | Proximity |
| Housing Material | Metal, CuZn, Nickel Plated |
| Operating Mode | Time of Flight |
| Operating Voltage | 15…30 VDC |
| Output Function | PNP |
| Protection Class | IP67 |
| Radiation Direction | side |
| Range | 25…400 mm |
| Resolution | 0.5 mm |
| Switching Element Function | NO/NC |
Specifications
| SKU | CS3875301 |
|---|---|
| MPN | RU40U-M18MS-AP8X2-H1151 |
| Alternate Part # | 1610105 |
| UPC/EAN | 4047101430240 |
