Turck RI-12I15E-2K1024-C2M

SKU: CS3832659MPN: RI-12I15E-2K1024-C2MAlternate Part #: 1545559

1545559 - INCREMENTAL

Turck RA-174TA4T2-29T-9A28B-R3M12, RI-02CA0S3-2D1024-C, RI-05I6T-2H1000-C, RI-05I8E-1H1000-H1181, RI-05I8E-1H2048-C, RI-05I8E-4A1000-H1181, RI-05I8E-4A1024-H1181, RI-05IA0T-2H100-C, RI-05IA0T-2H1000-C, RI-05IA0T-2H500-C, RI-10S8C-2B600-C1M, RI-12H10E-2K512-H1181/N22/N41, RI-12H10S1-2B1024-12M23, RI-12H10S1-4A1024-12M23, RI-12H10T-2K1024-12M23
$543.75
Unit
Available on backorder
remove
add

Product Details

Incremental Hollow Shaft Encoder

Industrial Line

  • Incremental Hollow Shaft Encoder
  • Protection class IP65 on shaft side
  • -40…+85 °C
  • Max. 12000 rpm (continuous operation 6000)
  • 5…30 VDC
  • Cable connection, 8-pole
  • Push-pull, with inverted signals
  • Pulse frequency max. 300 kHz
  • 1024 pulses per revolution

Attributes

Ambient Temperature -40…+85 °C
Ecl Ss Code V5 1 4 27270502 -/- Encoder, incremental
Electrical Connection Cable
Encoder Line Industrial-Line
Flange Diameter Ø  63 mm
Flange Type Flange with stator coupling
Housing Material Die-cast zinc
Operating Voltage 5…30 VDC
Output Function Push-Pull 7272, with inverted signals
Output Type Incremental
Protection Class IP67
Protection Class Housing IP65
Protection Class Shaft IP65
Resolution Incremental 1024  ppr
Shaft Diameter D Mm 15 mm
Shaft Type Hollow shaft
Technology Optical

Specifications

SKUCS3832659
MPNRI-12I15E-2K1024-C2M
Alternate Part #1545559
