Turck REI-E-114I10E-2B1024-H1181

SKU: CS3832159MPN: REI-E-114I10E-2B1024-H1181Alternate Part #: 100011765UPC/EAN: 4047101546170

100011765 - INCREMENTAL

Turck REI-E-114I10E-2B1024-H1181, REI-E-114I10E-2B5000-H1181, REI-E-114I12E-2B1024-H1181, REI-E-114I12E-2B360-H1181, REI-E-114I12E-2B5000-H1181, REI-E-114I8E-2B1024-H1181, REI-E-114I8E-2B2500-H1181, REI-E-114I8E-2B5000-H1181, RI-12H15E-2B1024-H1181, RI-12H15E-2K1024-H1181, RI-12I14E-4B3600-H1181, RI-12I14E-4B4096-H1181
Turck REI-E-114I10E-2B1024-H1181, REI-E-114I10E-2B5000-H1181, REI-E-114I12E-2B1024-H1181, REI-E-114I12E-2B360-H1181, REI-E-114I12E-2B5000-H1181, REI-E-114I8E-2B1024-H1181, REI-E-114I8E-2B2500-H1181, REI-E-114I8E-2B5000-H1181, RI-12H10E-2K512-H1181/N22/N41, RI-12H15E-2B1024-H1181, RI-12H15E-2K1024-H1181, RI-12I10E-4B4096-H1181, RI-12I14E-4B3600-H1181, RI-12I14E-4B4096-H1181
Turck REI-E-114I10E-2B1024-H1181, REI-E-114I10E-2B5000-H1181, REI-E-114I12E-2B1024-H1181, REI-E-114I12E-2B360-H1181, REI-E-114I12E-2B5000-H1181, REI-E-114I8E-2B1024-H1181, REI-E-114I8E-2B2500-H1181, REI-E-114I8E-2B5000-H1181, RI-12H15E-2B1024-H1181, RI-12H15E-2K1024-H1181, RI-12I14E-4B3600-H1181, RI-12I14E-4B4096-H1181
Turck REI-E-114I10E-2B1024-H1181, REI-E-114I10E-2B5000-H1181, REI-E-114I12E-2B1024-H1181, REI-E-114I12E-2B360-H1181, REI-E-114I12E-2B5000-H1181, REI-E-114I8E-2B1024-H1181, REI-E-114I8E-2B2500-H1181, REI-E-114I8E-2B5000-H1181, RI-12H10E-2K512-H1181/N22/N41, RI-12H15E-2B1024-H1181, RI-12H15E-2K1024-H1181, RI-12I10E-4B4096-H1181, RI-12I14E-4B3600-H1181, RI-12I14E-4B4096-H1181
$435.00
Unit
Available on backorder
remove
add

Product Details

Incremental Encoder

Efficiency Line

  • Flange with stator coupling, Ø 63 mm
  • Hollow shaft, Ø 10mm
  • Optical measuring principle
  • Shaft material: stainless steel
  • Protection class IP64 on housing and shaft side
  • ‐20…+70 °C
  • Max. 4500 rpm (continuous operation 3000 rpm)
  • 10…30 VDC
  • Male connector, M12 x 1 , 8-pole
  • Push-pull, with inverted signals
  • Pulse frequency max. 300 kHz
  • 1024 pulses per revolution

Attributes

Ambient Temperature -20…+70 °C
Customs Tariff Number 90318080000.0000
Ecl Ss Code V5 1 4 27270502 -/- Encoder, incremental
Electrical Connection Connector, M12 × 1
Encoder Line Efficiency-Line
Flange Diameter Ø  63 mm
Flange Type Flange with stator coupling
Housing Material Die-cast zinc
Operating Voltage 10…30 VDC
Output Function Push-Pull/HTL, with inverted signals
Output Type Incremental
Protection Class IP64
Protection Class Shaft IP64
Resolution Incremental 1024  ppr
Shaft Diameter D Mm 10 mm
Shaft Type Hollow shaft
Technology Optical

Specifications

SKUCS3832159
MPNREI-E-114I10E-2B1024-H1181
Alternate Part #100011765
UPC/EAN4047101546170
