Turck PT1VR-1013-IOL-H1141

SKU: CS3831573MPN: PT1VR-1013-IOL-H1141Alternate Part #: 100028555UPC/EAN: 4047101540833

100028555 - CER (REL) , SWITCH, GEN., GE

Turck PT1VR-1013-IOL-H1141
$294.11
Unit
Available on backorder
remove
add

Product Details

Pressure Transmitter

With 2 Switching Outputs and IO-Link

  • Ceramic measuring cell
  • Compact and robust design
  • Excellent EMC properties
  • Pressure range -1…0 bar rel.
  • 18…33 V DC
  • NO/NC contact, 2 × PNP/NPN outputs, IO-Link
  • Process connection G⅛″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
  • Connector device, M12 × 1

Attributes

Ambient Temperature -30…+85 °C
Approvals CE, Metrological certification (RUS), cULus
Communication Protocol IO-Link
Customs Tariff Number 90262020000.0000
Design Without display
Ecl Ss Code V5 1 4 27200614 -/- Piezoresistive sensor (absolute and relative pressure)
Electrical Connection Connector, M12 × 1
Electrical Output 2 × switching output
Housing Material Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Medium Temperature -40…+125 °C
Operating Voltage 18…33 VDC
Pressure Range Bar -1…0 bar
Pressure Range Psi -14.5…0 psi
Pressure Transducer Material Ceramic Al₂O₃
Pressure Type Relative pressure
Process Connection G⅛″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
Protection Class IP67

Specifications

SKUCS3831573
MPNPT1VR-1013-IOL-H1141
Alternate Part #100028555
UPC/EAN4047101540833
