Turck NI3-EH6.5-AN6X/S1367

SKU: CS3814156MPN: NI3-EH6.5-AN6X/S1367Alternate Part #: 100021801UPC/EAN: 4047101529036

100021801 - FERRITE, BARREL, DC, CABLE

Turck NI3-EH6.5-AN6X/S1367
$142.06
Unit
Available on backorder
remove
add

Product Details

Inductive Sensor

  • Smooth barrel, Ø 6.5 mm
  • Stainless steel, 1.4427 SO
  • DC 3-wire, 10…30 VDC
  • NO contact, NPN output
  • Cable connection

Attributes

Ambient Temperature -25…+70 °C
Construction Size Ø 6.5 mm
Customs Tariff Number 85365019900.0000
Design Smooth barrel
Ecl Ss Code V5 1 4 27270101 -/- Inductive proximity switch
Electrical Connection Cable
Housing Material Stainless steel, 1.4427 SO
Mounting Non-flush
Operating Voltage 10…30 VDC
Output Function NO contact, NPN
Protection Class IP67
Rated Switching Distance 3 mm
Switching Frequency 3.0 kHz

Specifications

SKUCS3814156
MPNNI3-EH6.5-AN6X/S1367
Alternate Part #100021801
UPC/EAN4047101529036
