Turck BIM-IKT-AN6X-H1141 W/KLI3
SKU: CS3790025MPN: BIM-IKT-AN6X-H1141 W/KLI3Alternate Part #: 4621190UPC/EAN: 4047101156188
4621190 - TRANS., RECT., DC, CON. M12
$116.71
UnitAvailable on backorder
Product Details
Magnetic Field Sensor
For Pneumatic Cylinders
- Rectangular, height 28 mm
- Metal, GD-Zn
- Magnetic-inductive sensor
- DC 3-wire, 10…30 VDC
- NO contact, NPN output
- M12 x 1 connector
Attributes
| Ambient Temperature | -25…+70 °C |
| Construction Size | 30 x 14.6 x 28 mm, IKT |
| Customs Tariff Number | 85365019900.0000 |
| Cylindrical Design | Tie-rod cylinder, Profile cylinder, Cylinder with external dovetail groove |
| Design | Rectangular |
| Ecl Ss Code V5 1 4 | 27270104 -/- Magnetic inductive proximity switch |
| Electrical Connection | Connector, M12 × 1 |
| Housing Material | Metal, GD-Zn |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, NPN |
| Protection Class | IP67 |
Specifications
| SKU | CS3790025 |
|---|---|
| MPN | BIM-IKT-AN6X-H1141 W/KLI3 |
| Alternate Part # | 4621190 |
| UPC/EAN | 4047101156188 |
