Turck BI5U-G18-RDZ30X2-B1331
SKU: CS3789639MPN: BI5U-G18-RDZ30X2-B1331Alternate Part #: 4281217UPC/EAN: 4047101136463
4281217 - UPROX, BARREL, AC, CON. ⅞IN.
$259.46
UnitAvailable on backorder
Product Details
Inductive Sensor
- Threaded barrel, M18 x 1
- Chrome-plated brass
- Factor 1 for all metals
- Protection class IP68
- Resistant to magnetic fields
- Extended temperature range
- High switching frequency
- AC 2-wire, 20…250 VAC
- DC 2-wire, 10…300 VDC
- NC contact
- ⅞” male connector
Attributes
| Ambient Temperature | -30…+85 °C |
| Construction Size | M18 x 1 |
| Customs Tariff Number | 85365080900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Connector, ⅞″ |
| Housing Material | Metal, CuZn, Chrome-plated |
| Mounting | Flush |
| Operating Voltage | 20…250 VAC / 10…300 VDC |
| Output Function | NC contact, 2-wire |
| Protection Class | IP68 |
| Rated Switching Distance | 5 mm |
| Special Feature | uprox+, Factor 1, Resistant to magnetic fields |
| Switching Frequency | 0.010 kHz |
Specifications
| SKU | CS3789639 |
|---|---|
| MPN | BI5U-G18-RDZ30X2-B1331 |
| Alternate Part # | 4281217 |
| UPC/EAN | 4047101136463 |
