Turck BI1.5-EGT08F-AG6X-0.2-RS4.23T
SKU: CS3787829MPN: BI1.5-EGT08F-AG6X-0.2-RS4.23TAlternate Part #: 4614686
4614686 - FERRITE, BARREL, DC, PIGTAIL M
Contact us for pricing and availability
Product Details
Inductive Sensor
Stainless Steel Front
- Threaded barrel, M8 x 1
- Stainless steel 1.4305
- PTFE-coated
- DC 2-wire, 10…30 VDC
- NO contact
- Cable with connector
Attributes
| Ambient Temperature | -25…+70 °C |
| Construction Size | M8 x 1 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Cable with connector, M12 × 1 |
| Housing Material | Stainless steel, 1.4305 (AISI 303), PTFE-coated |
| Mounting | Flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, 2-wire |
| Protection Class | IP67 |
| Rated Switching Distance | 1.5 mm |
| Special Feature | All-metal sensor, Pressure resistant |
| Switching Frequency | 0.20 kHz |
Specifications
| SKU | CS3787829 |
|---|---|
| MPN | BI1.5-EGT08F-AG6X-0.2-RS4.23T |
| Alternate Part # | 4614686 |
