Turck BI1.5-CRS524C-AP6X2-H1141
SKU: CS3787748MPN: BI1.5-CRS524C-AP6X2-H1141Alternate Part #: 4279091
4279091 - FERRITE, BARREL, DC, CON. M12
$467.21
UnitAvailable on backorder
Product Details
Inductive Sensor
For High Pressures
- Smooth barrel, stainless steel, 1.4305
- Ø 12.7 mm
- Housing, GD-Zn, chromated
- Special high pressure seal and active ceramic surface
- Permissible dynamic pressure 206 bar; static overpressure 310 bar
- DC 3-wire, 10…30 VDC
- NO contact, PNP output
- M12 x 1 male connector
Attributes
| Ambient Temperature | -25…+70 °C |
| Construction Size | Ø 12.7 mm |
| Design | Smooth barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Connector, M12 × 1 |
| Housing Material | Metal, 1.4305 (AISI 303) |
| Mounting | Flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, PNP |
| Protection Class | IP67 |
| Rated Switching Distance | 1.5 mm |
| Special Feature | Pressure resistant |
| Switching Frequency | 0.030 kHz |
Specifications
| SKU | CS3787748 |
|---|---|
| MPN | BI1.5-CRS524C-AP6X2-H1141 |
| Alternate Part # | 4279091 |
