Turck BI2-CRS603-AP4X2-H1141/S34
SKU: CS2426640MPN: BI2-CRS603-AP4X2-H1141/S34Alternate Part #: 4580096
4580096 - FERRITE, BARREL, DC, CON. M12
$341.58
UnitAvailable on backorder
Product Details
Inductive Sensor
for high pressures
- Smooth barrel, chrome-plated brass
- Ø 12.7 mm
- Housing, GD-Zn chromated
- Admissible pressure static/dynamic 200/100 bar
- Magnetic-resistant (insensitive to magnetic DC and AC fields)
- DC 3-wire, 10…65 VDC
- NO contact, PNP output
- M12 x 1 male connector
Attributes
| Ambient Temperature | -25…+70 °C |
| Construction Size | Ø 12.7 mm |
| Design | Smooth barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Connector, M12 × 1 |
| Housing Material | Metal, 1.4305 (AISI 303) |
| Mounting | Flush |
| Operating Voltage | 10…65 VDC |
| Output Function | NO contact, PNP |
| Protection Class | IP67 |
| Rated Switching Distance | 2 mm |
| Special Feature | Pressure resistant |
| Switching Frequency | 0.030 kHz |
Specifications
| SKU | CS2426640 |
|---|---|
| MPN | BI2-CRS603-AP4X2-H1141/S34 |
| Alternate Part # | 4580096 |
