Resideo VR8215S1248T

Single Stage Gas Controls for Direct Ignition appliance, ½ in x ½ in inlet/outlet size, Standard Opening, 24 V AC, Natural Gas

Product Overview:

• Combination gas control for use with hot surface/direct spark systems in 24 Vac, gas-fired appliances, with capacities from 30 to 415 cfh.

Product Features:

• Controls include manual valve, two automatic operators, and pressure regulator
• Use with S89C,E,F and S87 series 5 and later
• Compact size
• Provide two automatic valves
• Solenoid-operated first automatic valve opens on thermostat call for heat; closes when call for heat ends
• Diaphragm-operated second automatic valve opens under control of regulator; closes if gas or power supply is interrupted
• Meets codes requiring dual safety shut-off
• All adjustments, wiring connections and pilot outlet are accessible from top of control
• Adjustable servo regulator effectively maintains almost constant gas output pressure under wide fluctuations in gas supply pressure
• ON-OFF lighting sequence
• Natural to LP and LP to Natural conversion kits available for standard and slow opening gas valves
