Schneider Electric HO2XMSX-T1

Name: Schneider Electric HO2XMSX-T1
Brand: Schneider Electric
SKU: CS3338161
Availability: OutOfStock

SKU: CS3338161MPN: HO2XMSX-T1Alternate Part #: SENA-HO2XMSX-T1

RH Sensor, Schneider Electric, Deluxe, Outside, 2%, 4-20mA, STD

Product Details

Relative Humidity Sensor

Schneider Electric branded* Deluxe model* Outdoor mount* 2% Accuracy* 4-20mA output* Standard, US

Us Rated Supply Voltage	12…30 V DC
Us Rated Supply Voltage 1	12…30 V DC
Ambient Air Temperature For Operation	-40-50 °C
Ambient Air Temperature For Operation 1	-40-50 °C
Ambient Air Temperature For Operation 2	-40-50 °C
Colour	grey and white
Colour 1	grey and white
Device Application	outdoor reference
Humidity Measurement Drift	± 1 % at 20 °C annually, for 2 years
Humidity Measurement Resolution	0.1 % RH
Location	outdoor
Mounting Support	outdoor wall
Product Or Component Type	sensor
Range Of Product	HO
Relative Humidity	0-100 % RH, non-condensing (will recover from saturation)
Relative Humidity 1	0-100 % RH, non-condensing (will recover from saturation)
Sensor Type	humidity: thin film capacitive, replaceable
Sensor Type 1	humidity: thin film capacitive, replaceable
Targeted Region	North America.
Type Of Measurement	humidity
