Parker B723BB549A

Solenoid Air Control ½ 24VDC

Solenoid Air Control Valve Valve Ways and Positions 4-Way/2-Position Voltage 24V DC Valve Actuator / Return Solenoid / Solenoid Pipe Size ½ in Max CFM - Valves 5.9 cfm Operational Pressure Range 35 to 145 psi NEMA Classification NEMA 4 Valve Vacuum Range 0 to 28 in Hg Body Style Body Ported Pilot Port Size ½ in NPT Coefficient of Volume 5.9 15mm 3-Pin Male DIN Electrical Connections Ambient Temp Range 5 Degrees to 120 Degrees F Override Non-Locking Flush Overall Height 3 in
