Belimo B216
SKU: CS3014873MPN: B216
Characterized Control Valve (CCV), ½”, 2-way, Cv 16
$89.70
Unit4 Units Available at Factory - Ships Same/Next Business Day
Documents
Product Details
Characterized Control Valve (CCV), ½”, 2-way, Cv 16
Attributes
| Valve Size | 0.5” [15] |
| Cv | 16.0 |
| Flow Pattern | 2-way |
| Valve Trim | Stainless steel |
| Close-Off Pressure ∆Ps | 200 psi |
| Pressure Independent | NO |
| Fluid | chilled or hot water, up to 60% glycol |
| Controllable Flow Range | 75° |
| Pipe Connection | NPT female ends |
| Fluid Temp Range (Water) | 0…250°F [-18…120°C] |
| Cv Range [Gpm] | 7.6…16 |
| Pipe Connection Type | internal thread |
| Kvs Range [M³/H] | 6.6…14 m³/h |
| Flow Characteristic | equal percentage |
| Servicing | maintenance-free |
| Valve Body | Nickel-plated brass body |
| Stem | stainless steel |
| Seat | PTFE |
| Stem Seal | EPDM (lubricated) |
| Characterized Disc | No Disc (full flow) |
| Body Pressure Rating | 600 psi |
| O-Ring | EPDM (lubricated) |
| Ball | stainless steel |
Specifications
| SKU | CS3014873 |
|---|---|
| MPN | B216 |
