Johnson Controls V-3766-1001

½” NO OF 3-6# W/A 1.0CV

½” Normally Open Pneumatic Flare Valve, 3 to 6 psig (1.0 Cv)

Features:

• ½ in. OD SAE 45 flare connections do not require solder installation with copper tubing; provides easy removal for maintenance
• Standard Johnson Controls® non-adjustable ring pack packings provide proven reliability and long life
• Body rated 400 psig static pressure does not restrict building location
• Every valve tested for tight initial and long-term shutoff; ensures occupant comfort and energy conservation
• Factory-assembled valves available with pneumatic or electric actuators; install quickly and easily, minimizing job site time

**Image may not represent actual item.
