Veris EP3030S2
SKU: CS2541676MPN: EP3030S2Alternate Part #: VER-EP3030S2
Differential Air Pressure Trans: For the monitoring of air ducts, filters and fans, SPD310-100/300/500/1000Pa
$255.69
UnitAvailable on backorder
Product Details
TransducerElectropneumatic
- Standard* Pressure Loss Alarm, or Manual Mode Alarm* EP Cover Plate
Attributes
| Analogue Output Type | 4…20 mA; 0…10 V DC |
| Product or Component Type | sensor |
| Ambient Air Temperature for Operation | 5-60 °C |
| Product Certifications | CE |
| Controlled Fluid | dry air; inert gas |
| Fitting Size | 4.3 mm (0.18”) |
| Fitting Type | male |
| Location | plant room |
| Pressure Measurement Accuracy | ± 1 % FS |
| Pressure Measurement Range | 3…15 psi (0.2…1 bar); 0…20 psi (0…1.35 bar) |
| Wiring Technique | 3-wire |
| Type of Measurement | electropneumatic transducer |
| Device Application | pneumatic actuated dampers; pneumatic actuators |
| Mounting Support | panel |
| Standards | EN 61000-6-1 |
| Relative Humidity | 10-90 % RH, non-condensing |
| (Us) Rated Supply Voltage | 20…30 V AC; 22…30 V DC |
| Analogue Input tType | 4…20 mA; 0…5 V; 0…10 V; tri-state; PWM |
| Local Signalling | red/green LED |
Specifications
| SKU | CS2541676 |
|---|---|
| MPN | EP3030S2 |
| Alternate Part # | VER-EP3030S2 |
