Johnson Controls VA9208-GGA-3

ROTARY ACTUATOR; 70 LB IN; (8N-M) SPRING RETURN DIRECT-COUPLED ACTUATOR

The VA9208-GGx-x Series Actuators provide proportional modulation of VG1000 1-¼, 1-½, and 2 inch ball valves in HVAC systems that are controlled by an electronic controller or positioner. The actuator responds to 0 to 10 VDC or 2 to 10 VDC control signals. With the addition of a 500 ohm resistor, the actuator responds to a 0 to 20 mA or 4 to 20 mA signal. A 0 to 10 VDC or 2 to 10 VDC feedback signal indicates position and provides support for master-slave applications.

The VA9208-GGA-3 actuators include plenum-rated cables and are specially configured for installation in spaces used for environmental air-handling purposes, other than ducts and plenums, as specified in National Fire Protection Association (NFPA) 70: National Electrical Code section 300.22©, Other Space Used for Environmental Air. The space over a hung ceiling, when used for environmental air handling purposes, is an example of the type of space for which these actuators are configured.

Note: Image depicts Model VA9208-BGC-3
