Process InstrumentationTurck

Turck NI15U-EM18-AP6X-H1141

SKU: CS2456725MPN: NI15U-EM18-AP6X-H1141Alternate Part #: 1635332UPC/EAN: 4047101130836

1635332 - UPROX, BARREL, DC, CON. M12

Turck NI10-EM18-Y1X-H1141, NI10-M18-AN6X-H1141, NI10-M18-AP6X-H1141, NI10-M18-Y1X-H1141, NI12U-EM18-AN6X-H1141, NI12U-EM18-AP6X-H1141, NI12U-EM18-AP6X2-H1141, NI12U-EM18-RP6X-H1141, NI12U-M18-AN6X-H1141, NI12U-M18-AP6X-H1141, NI14-M18-AD4X-H1141, NI14-M18-AD4X-H1144, NI14-M18-AN6X-H1141, NI14-M18-AP6X-H1141, NI14-M18-RP6X-H1141
$153.61
Unit
Available on backorder
remove
add

Product Details

Inductive Sensor

With Extended Switching Distance

  • Threaded barrel, M18 x 1
  • Stainless steel, 1.4301
  • Factor 1 for all metals
  • Protection class IP68
  • Resistant to magnetic fields
  • Large switching distance
  • Integrated protection against predamping
  • Little metal-free spaces
  • DC 3-wire, 10…30 VDC
  • NO contact, PNP output
  • M12 x 1 male connector

Attributes

Ambient Temperature -30…+85 °C
Construction Size M18 x 1
Customs Tariff Number 85365019900.0000
Design Threaded barrel
Ecl Ss Code V5 1 4 27270101 -/- Inductive proximity switch
Electrical Connection Connector, M12 × 1
Housing Material Stainless steel, 1.4301 (AISI 304)
Mounting Non-flush
Operating Voltage 10…30 VDC
Output Function NO contact, PNP
Protection Class IP68
Rated Switching Distance 15 mm
Special Feature uprox+, Factor 1, Resistant to magnetic fields
Switching Frequency 1.0 kHz

Specifications

SKUCS2456725
MPNNI15U-EM18-AP6X-H1141
Alternate Part #1635332
UPC/EAN4047101130836
