All ProductsTurck

Turck BI15-Q20-Y1X-H1141

SKU: CS2452051MPN: BI15-Q20-Y1X-H1141Alternate Part #: 1080025UPC/EAN: 4047101064872

1080025 - FERRITE, RECT., NAMUR, CON. M1

Turck BI15-Q20-AN6X2-H1141, BI15-Q20-AP6X2-H1141, BI15-Q20-Y1X-H1141, BI15U-Q20-AN6X2-H1141, BI15U-Q20-AP6X2-H1141, BI15U-Q20-RP6X2-H1141, BI20-Q20-AN45X2LD-H1141, BI20-Q20-AP45X2LD-H1141, NI25-Q20-AN6X2-H1141, NI25-Q20-AP6X2-H1141, NI25NF-Q20-AN6X2-H1141
$101.31
Unit
Available on backorder
remove
add

Product Details

Inductive Sensor

  • Rectangular, height 20 mm
  • Active face on top
  • Plastic, PBT-GF30-V0
  • DC 2-wire, nom. 8.2 VDC
  • Output acc. to DIN EN 60947-5-6 (NAMUR)
  • M12 x 1 male connector
  • ATEX category II 2 G, Ex Zone 1
  • ATEX category II 1 D, Ex Zone 20
  • SIL 2 (Low Demand Mode) acc. to IEC 61508, PL c acc. to ISO 13849-1 at HFT0
  • SIL 3 (All Demand Mode) acc. to IEC 61508, PL e acc. to ISO 13849-1 with redundant configuration HFT1

Attributes

Ambient Temperature -25…+70 °C
Approvals ATEX II 2 G, ATEX II 3 G, ATEX II 1 D, ATEX II 2 D, ATEX II 3 D, SIL2, PLc
Construction Size 68 x 40 x 20 mm, Q20
Customs Tariff Number 85365019900.0000
Design Rectangular
Ecl Ss Code V5 1 4 27270101 -/- Inductive proximity switch
Electrical Connection Connector, M12 × 1
Housing Material Plastic, PBT-GF30-V0
Mounting Flush
Output Function NAMUR
Protection Class IP67
Rated Switching Distance 15 mm
Switching Frequency 1.0 kHz

Specifications

SKUCS2452051
MPNBI15-Q20-Y1X-H1141
Alternate Part #1080025
UPC/EAN4047101064872
