Turck IM31-11EX-U
SKU: CS2433751MPN: IM31-11EX-UAlternate Part #: 7506327UPC/EAN: 4047101116953
7506327 - IM.AI.1-CHANNEL
$414.90
UnitAvailable on backorder
Product Details
Analog signal isolator
1-channel
- Transmission of normalized analog signals from the Ex area to the non-Ex area
- Input circuit: 0/2…10 V or 0/4…20 mA
- Output circuit: 0/2…10 V
- Complete galvanic isolation
- Input reverse-polarity protected
- ATEX, IECEx, UL, CFMUS, TR CU, NEPSI, KOSHA
- Installation in zone 2
Attributes
| Approvals | ATEX, IECEx, UL, cFMus, TR CU, NEPSI |
| Customs Tariff Number | 85437090990.0000 |
| Device Type | Analog signal isolator - Input field side |
| Ecl Ss Code V5 1 4 | 27210107 -/- Transducer (universal) |
| Electrical Connection | 4 × 3-pin removable terminal blocks, reverse polarity protected, screw terminal |
| Ex Version | yes |
| Nominal Voltage | Wide voltage range |
| Number Of Channels | 1 |
| Product Series | IM |
| Protection Class | IP20 |
| Signal Type | Analog input |
Specifications
| SKU | CS2433751 |
|---|---|
| MPN | IM31-11EX-U |
| Alternate Part # | 7506327 |
| UPC/EAN | 4047101116953 |
