Schneider Electric AH23A020
SKU: CS204675MPN: AH23A020UPC/EAN: 711426604108
Act (AH23A020): Elec, 2Pos, SR, 24 VAC, App, Rotary, N1, Erie PopTop
$84.37
Unit15 in stock
Product Details
Actuator: (AH23A020):
- Actuator Type: Electric
- Control Signal: 2-Position (On/Off)
- Loss of Power Type: Spring Return
- Power Input Voltage: 24 VAC
- Leads and Connections: 18 in Appliance
- Mechanical Movement: Rotary
- Protection Rating: NEMA 1
- Product Line: Schneider Electric
- Product Range: Erie PopTop
- Product Series: AH
- Actuator Use: Zone Valves
Attributes
| Us Rated Supply Voltage | 24 V AC |
| Actuator | rotary |
| Ambient Air Temperature For Operation | 0-93.3 °C |
| Ambient Air Temperature For Storage | -40-71 °C |
| Control Type | automatic reset |
| Ip Degree Of Protection | IP10 |
| Motor Type | AC synchronous servo motor |
| Nema Degree Of Protection | NEMA 1 |
| Power Consumption In Va | 7.5 VA AC |
| Product Destination | zone valves |
| Product Or Component Type | actuator |
| Relative Humidity | 5-95 % non-condensing |
| Switch Function | No |
| Targeted Region | North America. |
| Taxoclass Id | PTC_D54013_XXX |
Specifications
| SKU | CS204675 |
|---|---|
| MPN | AH23A020 |
| UPC/EAN | 711426604108 |
