Square D ZC2JC1

Name: Square D ZC2JC1
Brand: Square D
SKU: CS1655909
Availability: OutOfStock

SKU: CS1655909MPN: ZC2JC1

Limit switch body, Limit switches XC Standard, ZC2J, fixed, without display, 1C/O

Product Details

Limit switch body ZC2J, fixed, without display, 1C/O

Ithe Conventional Enclosed Thermal Current	0.417
Ambient Air Temperature For Storage	-40-70 °C
Associated Head	ZC2JE64# #ZC2JE70# #ZC2JE03# #ZC2JE63# #ZC2JE65# #ZC2JE05# #ZC2JE66# #ZC2JE09# #ZC2JE61# #ZC2JE62# #ZC2JE02# #ZC2JE01
Body Material	metal
Body Type	fixed
Contact Operation	snap action
Contacts Material	silver plated contacts
Contacts Type And Composition	1 C/O
Device Short Name	ZC2J
Environmental Characteristic	standard environment
Ik Degree Of Protection	IK08
Ip Degree Of Protection	IP65
Local Display	without
Minimum Actuation Speed	0.01 m/min
Number Of Poles	1.0
Positive Opening	without
Product Compatibility	XC2J
Product Or Component Type	limit switch body
Range Of Product	Telemecanique Limit switches XC Standard
Series Name	standard format
Terminals Description Iso N 1	(13-14)NO# #(11-12)NC
