Square D 9007C54N2

Name: Square D 9007C54N2
Brand: Square D
SKU: CS105550
Availability: InStock

SKU: CS105550MPN: 9007C54N2UPC/EAN: 785901557647

Limit switch, 9007, 600 V 10amp c +options

Square D 9007C54B1, 9007C54N2, 9007C62A2, 9007C62C, 9007C66B2

7 in stock

Product Details

Heavy Duty Limit Switch Actuator Style - Limit Switch No Lever Rotary Actuator Location - Limit Switch Side AC Contact Rating - Limit Switch 10A @ 600V DC Contact Rating - Limit Switch 10A @ 600V Contact Form- Switches 1NC/1NO Body Height - Limit Switch 2.5 in Body Width - Limit Switch 0.83 in Body Depth - Limit Switch 1.14 in Boot Sealed Actuator - Limit Switch No Body Style - Limit Switch Miniature NEMA Rating 1 12 13 2 4 6 6P Mounting - Limit Switch Surface

Attributes

Ithe Conventional Enclosed Thermal Current	0.417
Ambient Air Temperature For Storage	-20-185 °F
Body Material	zinc
Body Type	plug-in
Contact Form	Form Z
Contact Operation	snap action
Contacts Material	silver contacts
Contacts Type And Composition	NC-NO
Device Short Name	9007C
Electrical Durability	1000000 cycles
Environmental Characteristic	standard environment
Fixing Mode	by the body
Function Available	-
Head Material	zinc
Head Type	rotary head
Material	metal
Maximum Displacement Angle	90 °
Mechanical Durability	10000000 cycles
Movement Of Operating Head	rotary
Number Of Poles	1
Positive Opening	without
Product Or Component Type	limit switch
Product Specific Application	standard box
Protective Treatment	epoxy powder coat
Range Of Product	9007
Sale Per Indivisible Quantity	1.0000
Series Name	heavy duty
Switch Actuation	CW and CCW# #from left and right
Switch Function	SPDT-DB
Terminals Description Iso N 1	(3-4)NO# #(1-2)NC
