All ProductsSchneider Electric

Schneider Electric VS-7223-593-4-09

SKU: CS100352MPN: VS-7223-593-4-09UPC/EAN: 711426004823

SmartX, Globe Valve Assembly, 1-¼ in, 2-way, Stem Up Close, 20 cv, 150 PSI, Spring Return, Normally Close, 24 VAC/VDC, Appliance, 220 lbf, Linear

Schneider Electric VA-7223-593-4-09, VA-7223-593-4-10, VA-7223-593-4-11, VS-7223-593-4-09, VS-7223-593-4-10, VS-7223-593-4-11, VS-7263-593-4-62, VS-7263-593-4-72, VS-7283-593-4-11
$963.41
Unit
Available on backorder
remove
add

Product Details

Valve Assembly:

  • Body Size: 1-¼ in
  • Configuration: 2-Way
  • Type: Globe
  • Body Pattern: Straightway
  • Connection: NPT
  • Stem Flow Action: Stem up A closed
  • Material Trim: Brass
  • Flow Coefficient: 20 cv
  • Close-Off Pressure: 150 PSI
  • Actuator Type: Electric
  • Control Signal: Proportional
  • Control Signal Range: 2 to 10 VDC, 4 to 20 mAdc
  • Loss of Power Type: Spring Return
  • Loss of Power Position: Normally closed
  • Power Input Voltage: 24 VAC/VDC, 22 to 30 VDC
  • Leads and Connections: 3 ft Appliance
  • Force: 220 lbf
  • Mechanical Movement: Linear
  • Protection Rating: NEMA 2

Assembly Components:

  • Valve Body: VB-7223-0-4-09
  • Valve Range: Venta
  • Valve Linkage: None, tool-less connection
  • Actuator: MS51-7203
  • Actuator Range: SmartX Actuator

Attributes

Us Rated Supply Voltage 22…30 V DC 24 V AC/DC
Actuator linear
Ambient Air Temperature For Operation -17.7-60 °C
Ambient Air Temperature For Storage -40-71 °C
Analogue Input Range 2…10 V DC 4…20 mA DC
Body Material bronze
Control Type automatic reset
Current Consumption 290 mA
Electrical Insulation Class class II
Force Lbf 220 lbf
Force N 979 N
Motor Type brushless DC motor
Operating Fluid Temperature -7-138 °C
Product Destination globe valve
Product Or Component Type valve-actuator assembly
Relative Humidity 15-95 % non-condensing
Saturated Steam Temperature -7-138 °C
Satured Steam Inlet Pressure 35 psi
Seat Leakage Port A: Class IV (0.01 %) Port A: Class V
Seat Material Port A: bronze
Seating Seal Material Port A:EPDM (ethylene propylene diene monomer)
Switch Function No
Targeted Region North America.
Taxoclass Id PTC_D54038_XXX

Specifications

SKUCS100352
MPNVS-7223-593-4-09
UPC/EAN711426004823
