Schneider Electric Valve-Actuator Assemblies

VB: 1-¼ in, 2W, Globe, STR, NPT, UO, BR, 20 cv, 15 PSI, Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, NO, Air NPT, Linear, N1

VB: ¾ in, 2W, Zone, FLR, BR, 2.5 cv, 40 PSI, Act (AG14B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

Valve Linkage Extension Kit

VB: ½ in, 2W, Zone, NPT, BR, 2.5 cv, 40 PSI, Act (AG13B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

VB: ¾ in, 2W, Zone, NPT, BR, 2.5 cv, 50 PSI, Act (AH13B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

VB: ¾ in, 3W Mix/Div, Zone, NPT, BR, 4 cv, 25 PSI, Act (AG13B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

VB: ½ in, 2W, Zone, SWT, BR, 3.5 cv, 25 PSI, Act (AG13B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

VB: ½ in, 3W Mix/Div, Zone, SWT, BR, 4 cv, 25 PSI, Act (AG13A020): Elec, 2Pos, SR, NC, 24 VAC, App, N1

VB: ½ in, 2W, Zone, NPT, BR, 4 cv, 35 PSI, Act (AP33A000): Elec, Prop, 0-10 VDC/4-20mAdc, NSR, 24 VAC, No Leads, N1

VB: ¾ in, 3W Mix, Zone, SWT, BR, 2 cv, 20 PSI, Act (AP13A000): Elec, Prop, 0-10 VDC/4-20mAdc, SR, NC, 24 VAC, No Leads, N1

VB: ⅝ in, 2W, Globe, STR, FLR, UC, BR, 1.3 cv, 50 PSI, Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, NC, Air NPT, Linear, N1

VB: ¾ in, 2W, Globe, STR, NPT, UO, BR, 7.5 cv, 60 PSI, Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, NO, Air NPT, Linear, N1

VB: ¾ in, 2W, Zone, NPT, BR, 3.5 cv, 25 PSI, Act (AG13B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

VB: ½ in, 3W Mix/Div, Zone, SWT, BR, 4 cv, 25 PSI, Act (AG14T020): Elec, 2Pos, SR, NC, 277 VAC, App, N1

VB: ½ in, 2W, Zone, NPT, BR, 2.5 cv, 40 PSI, Act (AG14A020): Elec, 2Pos, SR, NC, 24 VAC, App, N1

VB: 10 in, 2W, BFV, FLG, Full, FE, 5430 cv, 175 PSI, Act (BRY-S70-120-0301-H): Elec, 2Pos, NSR, 120 VAC, TB, 600 in-lb, SPDT, HTR

VB: ½ in, 3W Mix, Globe, NPT, BR, 2.2 cv, 150 PSI, Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, NC, Air NPT, Linear, N1

VB: ½ in, 2W, Zone, NPT, BR, 3.5 cv, 30 PSI, Act (AH23A020): Elec, 2Pos, SR, NO, 24 VAC, App, N1

Erie PopTop, Zone Valve Assemblie, ½ in, 2-Way, Sweat, Brass, 2 cv, 50 PSI, Floating, Non-Spring Return, 24 VAC, No Leads, Time-out, NEMA 1

VB: ½ in, 2W, Zone, NPT, BR, 2.5 cv, 40 PSI, Act (AG23A020): Elec, 2Pos, SR, NO, 24 VAC, App, N1

VB: ½ in, 2W, Zone, NPT, BR, 2.5 cv, 40 PSI, Act (AG24U020): Elec, 2Pos, SR, NO, 110-240 VAC, App, N1

VB: ½ in, 2W, Globe, STR, NPT, UO, BR, 2.2 cv, 90 PSI, Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, NO, Air NPT, Linear, N1

VB: ¾ in, 2W, Zone, SWT, BR, 2.5 cv, 50 PSI, Act (AH23A020): Elec, 2Pos, SR, NO, 24 VAC, App, N1

VB: ⅝ in, 3W Mix, Globe, FLR, BR, 4.4 cv, 250 PSI, Act (MK-4621): Pneu, 2Pos/Prop, 10-13 PSIG, SR, NC, Air NPT, Linear, N1

Plunger For AV-29

VB: ¾ in, 3W Mix/Div, Zone, FLR, BR, 3 cv, 40 PSI, Act (AG14B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

VB: 1-½ in, 2W, Globe, STR, NPT, UO, BR, 28 cv, 170 PSI, Act (MK-6601): Pneu, 2Pos/Prop, 3-8 PSIG, SR, NO, Air NPT, Linear, N1

VB: ½ in, 2W, Zone, SWT, BR, 3.5 cv, 25 PSI, Act (AG13A020): Elec, 2Pos, SR, NC, 24 VAC, App, N1

VB: ¾ in, 3W Mix/Div, Zone, NPT, BR, 3 cv, 40 PSI, Act (AG13A020): Elec, 2Pos, SR, NC, 24 VAC, App, N1

VB: ¾ in, 2W, Zone, FLR, BR, 3.5 cv, 30 PSI, Act (AH14A020): Elec, 2Pos, SR, NC, 24 VAC, App, N1

VB: ⅝ in, 2W, Globe, STR, FLR, UO, BR, 1.3 cv, 90 PSI, Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, NO, Air NPT, Linear, N1

VB: 1-¼ in, 2W, Globe, STR, NPT, UC, BR, 20 cv, 40 PSI, Act (MK-4621): Pneu, 2Pos/Prop, 10-13 PSIG, SR, NC, Air NPT, Linear, N1

Erie PopTop, Zone Valve Assemblie, ½ in, 2-Way, Sweat, Brass, 1 cv, 50 PSI, Floating, Non-Spring Return, 24 VAC, No Leads, NEMA 1

VB: 1 in, 2W, Globe, STR, NPT, UO, BR, 10 cv, 90 PSI, Act (MK-4601): Pneu, 2Pos/Prop, 3-6 PSIG, SR, NO, Air NPT, Linear, N1

SmartX, Globe Valve Assembly, ½ in, 2-Way, Stem Up Close, 0.4 cv, MF51-7103-100 Spring Return Proportional Actuator

VB: 1 in, 2W, Globe, ANG, NPT, UO, BR, 16 cv, 25 PSI, Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, NO, Air NPT, Linear, N1

VB: ½ in, 2W, Zone, NPT, BR, 2.5 cv, 40 PSI, Act (AG13A020): Elec, 2Pos, SR, NC, 24 VAC, App, N1

VB: 1 in, 2W, Globe, STR, NPT, UO, BR, 14 cv, 25 PSI, Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, NO, Air NPT, Linear, N1

VB: ½ in, 2W, Globe, STR, NPT, UO, BR, 2.2 cv, 90 PSI, Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, NO, Air NPT, Linear, N1

VB: ¾ in, 3W Mix, Zone, NPT, BR, 7.5 cv, 15 PSI, Act (AP13A000): Elec, Prop, 0-10 VDC/4-20mAdc, SR, NC, 24 VAC, No Leads, N1

VB: ¾ in, 2W, Zone, NPT, BR, 7.5 cv, 17 PSI, Act (AG14B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

Erie PopTop, Zone Valve Assemblie, ½ in, 2-Way, NPT, Brass, 2 cv, 50 PSI, Floating, Non-Spring Return, 24 VAC, No Leads, NEMA 1

VB: ½ in, 2W, Zone, SWT, BR, 2.5 cv, 40 PSI, Act (AG13A020): Elec, 2Pos, SR, NC, 24 VAC, App, N1

VB: ½ in, 2W, Zone, SWT, BR, 2.5 cv, 40 PSI, Act (AG23A020): Elec, 2Pos, SR, NO, 24 VAC, App, N1

SmartX, Globe Valve Assembly, ½ in, 2-way, 1.3 Cv, stem up open, MS51-7203-100 proportional spring return actuator

SmartX, Globe Valve Assembly, 1 in, 2-Way, Stem Up Open, 14 cv, MS40-7043 Spring Return Proportional Actuator

VB: 1 in, 3W Mix/Div, Zone, NPT, BR, 8 cv, 17 PSI, Act (AG13B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

VB: ¾ in, 2W, Zone, NPT, BR, 2.5 cv, 40 PSI, Act (AG23A020): Elec, 2Pos, SR, NO, 24 VAC, App, N1

Erie PopTop, Zone Valve Assemblie, ¾ in, 2-Way, NPT, Brass, 2 cv, 50 PSI, Floating, Non-Spring Return, 24 VAC, No Leads, NEMA 1

VB: ½ in, 3W Mix/Div, Zone, NPT, BR, 3 cv, 40 PSI, Act (AG13A020): Elec, 2Pos, SR, NC, 24 VAC, App, N1

SmartX, Globe Valve Assembly, 2 in, 2-Way, Stem Up Close, 40 Cv, MS40-7043-501 Spring Return Proportional Actuator

VB: ¾ in, 3W Mix/Div, Zone, FLR, BR, 1.5 cv, 60 PSI, Act (AG13B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

VB: ½ in, 2W, Zone, NPT, BR, 3.5 cv, 25 PSI, Act (AG13B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1

VB: ½ in, 3W Mix/Div, Zone, NPT, BR, 4 cv, 30 PSI, Act (AH13A020): Elec, 2Pos, SR, NC, 24 VAC, App, IP31

SmartX, Globe Valve Assembly, ½ in, 2-Way, Stem Up Close, 1.3 cv, MF51-7103-100 Spring Return Proportional Actuator

VB: 1-¼ in, 3W Mix, Zone, SWT, BR, 8 cv, 35 PSI, Act (AP33A000): Elec, Prop, 0-10 VDC/4-20mAdc, NSR, 24 VAC, No Leads, N1

SmartX, Globe Valve Assembly, ¾ in, 2-way, Stem Up Open, 7.5 cv, MF51-7103-100 Spring Return Proportional Actuator

Adapter Kit for Robertshaw V2566, V2567, V2568, V6600, V6700, and V6800 ½” - 2” Globe Valves

VB: 4 in, 2W, Globe, FLG, UO, BR, 145 cv, 125 PSI, Act (MS41-7153): Elec, Prop, 2-10 VDC/4-20 mAdc, SR, NO, 24 VAC/VDC, App, 133 in-lb, Rotary, N1/N2

VB: 2-½ in, 2W, Ball, NPT, SS, 202 cv, 70 PSI, Act (MS40-7043): Elec, Prop, 4-20 mAdc. SR, NO, 24 VAC, 22-30 VDC, Plen, 35 in-lb, Rotary, N2
