UV self-check scanner, 1” NPT, 102 - 264 VAC shutter. Use with 72DUVS4, 72DUVS1T, BurnerLogix, E-Series, MicroM, FlameWorx II.

2 line x 16 character backlit LCD display with keypad.

Ultraviolet self check amplifier. Use with 45UV5-1005, -1007, -1008, -1009, or 55UV5-1007, -1009.

Display 2 Lines 16 Characters

Pressure Transducer

SERVO-Motor 24VDC

UV self-check scanner. Meets Class 1, Div 2, Groups A, B, C, and D, NEMA 4X. 1” NPT, 102 - 260 VAC, 50/60 Hz.

Open wiring base for cabinet mtg., use with D Series and FLAME-MONITOR.

Keypad selectable parameters, non-recycle operation, modulation, open/closed damper proving, 4 second FFRT

Flame Sensor Module UV/UV-Self Check

UV, integrated flame scanner, 24 VDC, 1” NPT, 4 sec FFRT w/ 4-20 mA with quick disconnect. Use 59-598-xx cable. FM approved.

UV amp, .8 sec FFRT. Use with UV1, UV2, 45UV3.

UV self-checking, 1 inch NPT mount, 60 Hz. Use with 25SU3 and 25SU5.

1” NPT self-check UV scanner

Scanner ½ NPT 12 ft UV

UV Scanner

UV Scanner ½ 90 Deg 6 ft

Chassis, 120 VAC, 50/60 Hz with UV non self-check amplifier. UL, FM, CE Approved.

Union with quartz lens, ½” for UV1A.

Heat insulator, 1” NPT for 45UV5.

InSight II Flame Scanner - Dual detector (IR and UV) with single quick disconnect to connect to InSight I cable connector (e.g., 129-164). NEMA 4X,…

Temperature sensor, Range 32 deg. F to 752 deg. F (0 deg. C to 400 deg. C), 4-20 mA output, linear with temperature

Temperature Sensor 32 Deg-752 Deg F

Flame A. Module

120 VAC, 50/60 Hz Chassis with alpha-numeric display interface to ED510.

Infrared amp, 3 sec FFRT. Use with 48PT2 scanner.

Closed wiring base for surface mtg., use with M-Series II and MicroM.

UV Scanner Standard Mount with Tube

Flame Relay

UV Tube

UV self-check scanner, 1” NPT, 8’ lead, use with P-Series or MicroM / E-Series/BurnerLogix with 61-5745-3 drive circuit.

InSight I Flame Scanner - Dual detector (IR and UV) with quick disconnect. FM, UL/c Approved.

Amplifier, for use with EP178 / EP378 and one or two 85UVF4-1QDWR, 85IRF4-1QDWR, or InSight flame scanners (with 59-497-020WR cable).

Remote display (ED510) mounting kit with 8’ cable.

Infrared autocheck amplifier, use with 48PT2. Special application only, consult factory.

1” NPT mounting flange for Phoenix Series II and InSight Scanner, includes 35-127-1.

Expansion module wiring base.

Micro M Chassis

Chassis, 120 VAC, 50/60 Hz with IR Auto-Check amplifier. UL, FM, CE Approved.

UV amp, 0.8 sec FFRT. Use with UV1, UV2, 45UV3.

UV scanner, ½” NPT connector, 6 ft. cable rated for Tray Cable - Exposed Run (TC-ER).

120 VAC, 50/60 Hz Chassis.

Replacement Power Module for Multi-flame system.

120 VAC, 50/60 Hz Chassis with standard plug-in daughter board

Firetron cell for 48PT2 only.

½” NPT straight UV scanner, 6 ft flex conduit with insulated nylon coupling.

UV amp, 3 sec FFRT. Use with UV1, UV2, 45UV3.

½” NPT, 90 degree UV Scanner. 10 ft unshielded cable

Chassis UV Self Check 120V

Vacuum Fluorescent Display (VFD) for InSight II flame scanner.

UV scanner, ½” NPT connector, 3 ft. cable rated for Tray Cable - Exposed Run (TC-ER).

Replacement O2 probe for NX224455. Does not include mounting flange, ambient air sensor, or transformer.

Infrared scanner, 8’, 90 degree head, BurnerLogix, E-Series, MicroM

Ultraviolet amplifier, use with UV1, UV2, UV8, UV90, or 45UV3.

Closed wiring base for surface mtg., use with D Series and FLAME-MONITOR.

Control, consisting of EB700, 48-1836, EC600. 120 VAC. Display ordered separately. UL, FM, UL/c Approved.

Infrared scanner, 8’, straight head, BurnerLogix, E-Series, MicroM

Display module for 25SU5-5011/50125166/5168.

UV amp, 2-4 sec FFRT. Use with UV1, UV2, 45UV3.
