Siemens 283-03114

Name: Siemens 283-03114
Brand: Siemens Building Technologies
SKU: CS947031
Price: 877.96 USD
Availability: OutOfStock

SKU: CS947031MPN: 283-03114UPC/EAN: 4034106373870

Valve assy 2W NO, 1-¼” 16Cv Eq Pct SS Trim FxF, 8” Pneu Act w/ pos

Siemens Building Technologies 277-03004, 277-03006, 277-03008, 277-03020, 277-03025, 277-03026, 277-03058, 277-03059, 277-03061, 277-03062, 277-03074, 277-03076, 277-03078, 277-03079, 277-03080

$877.96

Unit

Available on backorder

Quantity

remove

add

Product Details

Flowrite 599 Series Valve Assembly features a 8-inch pneumatic actuator with factory-mounted positioner and 5 psi span. The 2-way, normally open, 1-¼-inch, 16 Cv valve assembly is ANSI Class 250 and has an equal percentage characteristic, stainless steel trim, and female x female end connections.

Attributes

Actuator Type	Pneumatic
Close Off Pressure	93 psi
Connecting Thread	Direct-coupled universal bonnet
End Connection	FxF
Fail Safe	Yes
Flow Characteristic	Equal-percentage
Flow Coefficient Cv	16.0000
High Temperature	NO
Leakage Rate	Class IV (0.01% of Cv)
Material Inside Set	Body Trim: Stainless Steel;Stem: Stainless Steel ASTM A582 Type 303;Normal Duty Packing: EPDM O-ring;Seat: Single seat metal-to-metal
Material Valve Body	UNS CA 844 bronze
Max Differential Pressure Liquid	50 psi
Max Differential Pressure Steam	15 psi
Max Inlet Pressure Absolute Liquid	400 psi
Max Inlet Pressure Absolute Steam	15 psi
Medium	Saturated steam;Water;Water with anti-freeze
Medium Temperature	20…250 ºF
Medium Temperature F Max	250 ºF
Medium Temperature F Min	20 ºF
Normally Open Normally Closed	Normally Open
Operating Voltage	Pneumatic
Permissible Operating Pressure	Max. recommended differential pressure for modulating service: 50 psi, 345 kPa
Port Configuration	2-Way Normally open
Rangeability	100:1
Spring Range	3-8 psi
Stroke	¾ in., 20 mm
Trim Material	Stainless Steel
Valve Body Style	Stroke-Globe
Valve Size	1.25 in
Valve Type	Two-way
