Turck BI2-CRS730-ADZ30X2-B3131/S34

SKU: CS852889MPN: BI2-CRS730-ADZ30X2-B3131/S34Alternate Part #: 4278293

4278293 - FERRITE, BARREL, AC, CON. ½I

Turck BI2-CRS1159-ADZ30X2-B3131/S34, BI2-CRS260-ADZ30X2-B3131/S34, BI2-CRS317-ADZ30X2-B3131/S34, BI2-CRS524-ADZ30X2-B3131/S34, BI2-CRS603-ADZ30X2-B3131/S34, BI2-CRS730-ADZ30X2-B3131/S34, BI2-CRS959-ADZ30X2-B3131/S34
$428.47
Unit
Available on backorder
remove
add

Product Details

Inductive Sensor

for high pressures

  • Smooth barrel, stainless steel, 1.4305
  • Ø 12.7 mm
  • Housing, GD-Zn, chromated
  • Admissible pressure static/dynamic 200/100 bar
  • Magnetic-resistant (insensitive to magnetic DC and AC fields)
  • AC 2-wire, 20…250 VAC
  • DC 2-wire, 10…300 VDC
  • NO contact
  • ½” male connector

Attributes

Ambient Temperature -25…+70 °C
Construction Size Ø 12.7 mm
Design Smooth barrel
Ecl Ss Code V5 1 4 27270101 -/- Inductive proximity switch
Electrical Connection Connector, ½″
Housing Material Metal, 1.4305 (AISI 303)
Mounting Flush
Operating Voltage 20…250 VAC / 10…300 VDC
Output Function NO contact, 2-wire
Protection Class IP67
Rated Switching Distance 2 mm
Special Feature Pressure resistant
Switching Frequency 0.020 kHz

Specifications

SKUCS852889
MPNBI2-CRS730-ADZ30X2-B3131/S34
Alternate Part #4278293
