Turck NI3-EG08K-AN6X-H1341
SKU: CS778861MPN: NI3-EG08K-AN6X-H1341Alternate Part #: 4669760UPC/EAN: 4047101159387
4669760 - FERRITE, BARREL, DC, CON. M12
$147.22
UnitAvailable on backorder
Product Details
Inductive Sensor
- M8 × 1 threaded barrel
- Stainless steel, 1.4305 (AISI 303)
- DC 3-wire, 10…30 VDC
- NO contact, NPN output
- M12 x 1 male connector
Attributes
| Ambient Temperature | -25…+70 °C |
| Construction Size | M8 x 1 |
| Customs Tariff Number | 85365019900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Connector, M12 × 1 |
| Housing Material | Stainless steel, 1.4305 (AISI 303) |
| Mounting | Non-flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, NPN |
| Protection Class | IP67 |
| Rated Switching Distance | 3 mm |
| Switching Frequency | 3.0 kHz |
Specifications
| SKU | CS778861 |
|---|---|
| MPN | NI3-EG08K-AN6X-H1341 |
| Alternate Part # | 4669760 |
| UPC/EAN | 4047101159387 |
