Siemens 261-02012
SKU: CS721147MPN: 261-02012UPC/EAN: 1P261-02012
Valve assy NC ¾” 6.3Cv FxF Brass Trim Elect Act NSR Mod 0-10 V
$252.58
UnitAvailable on backorder
Product Details
This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, Modulating 0-10 Volts and Fail in-place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 6.3 Cv, and a line size of ¾”.
Attributes
| Actuator Type | Electronic |
| Close Off Pressure | 40 psi |
| Control Signal | 0…10 Vdc |
| End Connection | FxF |
| Fail Safe | No |
| Flow Characteristic | Modified Equal-percentage |
| Flow Coefficient Cv | 6.3000001907349 |
| Max Differential Pressure Liquid | 25 psi |
| Max Differential Pressure Steam | 5 psi |
| Max Inlet Pressure Absolute Liquid | 400 psi |
| Max Inlet Pressure Absolute Steam | 5 psi |
| Medium | Water;Water with anti-freeze |
| Medium Temperature | 35…250 ºF |
| Medium Temperature F Max | 250 ºF |
| Medium Temperature F Min | 35 ºF |
| Operating Voltage | 24 VAC |
| Port Configuration | 2-Way Normally closed |
| Spring Return Function | Non-spring return functionality |
| Supply Voltage | 24 VAC |
| Trim Material | Brass |
| Valve Size | 0.75 in |
| Valve Type | Two-way |
Specifications
| SKU | CS721147 |
|---|---|
| MPN | 261-02012 |
| UPC/EAN | 1P261-02012 |
