Turck NI14-M18-AP6X-H1141
SKU: CS710934MPN: NI14-M18-AP6X-H1141Alternate Part #: 4611400UPC/EAN: 4047101099140
4611400 - FERRITE, BARREL, DC, CON. M12
$146.22
Unit4 in stock
Product Details
Inductive Sensor
With Increased Switching Distance
- Threaded barrel, M18 x 1
- Chrome-plated brass
- Large sensing range
- DC 3-wire, 10…30 VDC
- NO contact, PNP output
- M12 x 1 male connector
Attributes
| Ambient Temperature | -25…+70 °C |
| Construction Size | M18 x 1 |
| Customs Tariff Number | 85365019900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Connector, M12 × 1 |
| Housing Material | Metal, CuZn, Chrome-plated |
| Mounting | Non-flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, PNP |
| Protection Class | IP67 |
| Rated Switching Distance | 14 mm |
| Special Feature | Sn + |
| Switching Frequency | 0.50 kHz |
Specifications
| SKU | CS710934 |
|---|---|
| MPN | NI14-M18-AP6X-H1141 |
| Alternate Part # | 4611400 |
| UPC/EAN | 4047101099140 |
